Martin Audio C8.1T
Ceiling Mounted, Two-Way Vented Enclosure
Full-Range 8" System
Description
The enclosure is ported to extend the low frequency performance and the 5-point mounting system ensures that installation is fast and secure. Input and link terminals make paralleling units a simple operation and a steel cover plate protects the input connector against fire.
These products comply with UL2043 Fire Tests for Heat & Visible Smoke Release for Discrete Products and their Accessories Installed in Air Handling Spaces.
Listed UL1480 General Signalling Speakers.
SUITABLE FOR USE IN AIR HANDLING SPACES
C8.1T Features
- Two-way high performance flush mounting ceiling speaker
- 8" (200mm) UL94V-0 carbon fibre loaded polypropylene cone bass
- Wide dispersion – 90° conical up to 7kHz
- High & low impedance operation – transformer included
- 110dB max SPL @ 1 metre (16 ohm)
- 125 watt power handling (60W through transformer)
- Polyswitch and thermal fuse protected
- Steel backcan
- UL2043 & UL1480
Applications for the C8.1T
Resources & Downloads
Data sheets, manuals and resources for the C8.1T
Interested in this product?
Our AV experts are ready to help you find the perfect solution for your project.
Quick Specs
- TYPE
- Ceiling mounted, two-way vented enclosure
- FREQUENCY RESPONSE
- 80Hz-18kHz ± 3dB -10dB @ 50Hz
- DRIVER
- 8" (200mm) UL94V-0 PP bass driver, 1" (25mm) dome tweeter
- RATED POWER
- 125W AES, 500W peak
- SENSITIVITY
- 91dB
Technical Specifications
- TYPE
- Ceiling mounted, two-way vented enclosure
- FREQUENCY RESPONSE
- 80Hz-18kHz ± 3dB -10dB @ 50Hz
- DRIVER
- 8" (200mm) UL94V-0 PP bass driver, 1" (25mm) dome tweeter
- RATED POWER
- 125W AES, 500W peak
- SENSITIVITY
- 91dB
- MAXIMUM SPL
- 110dB continuous, 116dB peak
- NOMINAL IMPEDANCE
- 16Ω
- DISPERSION (-6dB)
- 90° conical up to 7kHz
- CROSSOVER
- 3kHz passive
- ENCLOSURE
- Steel backcan
- FINISH
- Bezel & grille – white UV resistant, Overpaintable, Backcan – zinc plated
- PROTECTIVE GRILLE
- Perforated steel
- CONNECTORS
- Rising clamp plug and socket
- ACCESSORIES (included)
- 60W 70/100V line transformer, Tile rails, C bracket, Paint mask, Cut-out template
- VOLTAGE TAPS
- 100V – 60W, 30W, 15W, 70V – 60W, 30W, 15W, 7.5W
- DIMENSIONS
- (OD) 354mm x (D) 258mm (OD) 13.9ins x (D) 10.2ins
- CUT-OUT DIAMETER
- 308mm (12.14 ins)
- WEIGHT
- 6.7kg (14.8lbs)
The enclosure is ported to extend the low frequency performance and the 5-point mounting system ensures that installation is fast and secure. Input and link terminals make paralleling units a simple operation and a steel cover plate protects the input connector against fire.
These products comply with UL2043 Fire Tests for Heat & Visible Smoke Release for Discrete Products and their Accessories Installed in Air Handling Spaces.
Listed UL1480 General Signalling Speakers.
SUITABLE FOR USE IN AIR HANDLING SPACES
- Two-way high performance flush mounting ceiling speaker
- 8" (200mm) UL94V-0 carbon fibre loaded polypropylene cone bass
- Wide dispersion – 90° conical up to 7kHz
- High & low impedance operation – transformer included
- 110dB max SPL @ 1 metre (16 ohm)
- 125 watt power handling (60W through transformer)
- Polyswitch and thermal fuse protected
- Steel backcan
- UL2043 & UL1480
| TYPE | Ceiling mounted, two-way vented enclosure |
| FREQUENCY RESPONSE | 80Hz-18kHz ± 3dB -10dB @ 50Hz |
| DRIVER | 8" (200mm) UL94V-0 PP bass driver, 1" (25mm) dome tweeter |
| RATED POWER | 125W AES, 500W peak |
| SENSITIVITY | 91dB |
| MAXIMUM SPL | 110dB continuous, 116dB peak |
| NOMINAL IMPEDANCE | 16Ω |
| DISPERSION (-6dB) | 90° conical up to 7kHz |
| CROSSOVER | 3kHz passive |
| ENCLOSURE | Steel backcan |
| FINISH | Bezel & grille – white UV resistant, Overpaintable, Backcan – zinc plated |
| PROTECTIVE GRILLE | Perforated steel |
| CONNECTORS | Rising clamp plug and socket |
| ACCESSORIES (included) | 60W 70/100V line transformer, Tile rails, C bracket, Paint mask, Cut-out template |
| VOLTAGE TAPS | 100V – 60W, 30W, 15W, 70V – 60W, 30W, 15W, 7.5W |
| DIMENSIONS | (OD) 354mm x (D) 258mm (OD) 13.9ins x (D) 10.2ins |
| CUT-OUT DIAMETER | 308mm (12.14 ins) |
| WEIGHT | 6.7kg (14.8lbs) |
